Adjustments:

Spring preload

QS3–3 position compression

QSR–3 position rebound

Features:

Optimized lightweight spring & shock design

Spiral groove bypass

FOX Ice Scraper Technology (FIST)

One-piece, aluminum spherical bearings

High-flow velocity-sensitive damping

Fully re-buildable and re-valvable

Top Mount: Eyelet

Bottom Mount: Eyelet

Rebuild P/n: FT: 803-01-569; RT: 803-01-571

Reservoir: Piggyback

Front Track Extended Length: 12.6300

Front Track Compressed Length: 8.4600

Front Track Travel: 5.3300

Rear Track Extended Length: 12.6300

Rear Track Compressed Length: 11.6800

Rear Track Travel: 5.3300

Fitment notes: Track (Front & Rear)
